IFR18650 3.2v 1400mAh LiFePO4 Battery Cell And PTC Protection

Large Image : IFR18650 3.2v 1400mAh LiFePO4 Battery Cell And PTC Protection Get Best Price

Product Details:

Place of Origin:	Shandong, China
Brand Name:	DISON
Certification:	CB
Model Number:	IFR18650

Payment & Shipping Terms:

Minimum Order Quantity:	1000 pieces
Price:	$0.98/pieces >=1000 pieces
Packaging Details:	Carton case or packed as per customer requirements
Supply Ability:	9000000 Piece/Pieces per Month

Contact Now

Detailed Product Description

Battery Size:	IFR18650 3.2v 1400mAh	Weight:	42
The Charging Ratio:	0.1C	The Discharge Rate:	0.2C
Anode Material:	LFP	Application:	Portable Medical Device
Battery Type:	18650 Rechargeable Li-ion	Capacity:	1400mAh
Voltage:	3.2v	Warranty:	3 Years, 5years
Cycle Life:	2000 Cycles	Keywords:	3.2v Lithium Ion Battery
Chargeable:	Yes	Port:	Qingdao

Product Overview

3.2V 1400mAh 18650 LFP battery cylindrical Lithium-ion LiFePO4 Battery Cell with PTC protection

*Using LiFePo4 as cathode material, cell voltage is 3.2V, platform capacity can reach more than 90%;
*Battery has long cycle life, 1 ItA cycle life＞2000 times, and the remaining capacity＞80% of the rated capacity;
*The P-O key in lithium ion phosphate crystal is stable, the decomposition temperature is up to 600 ℃, do not explode when
crushing or needling, the safety performance is good;
*High temperature charging and discharging performance is good, the discharge capacity＞98% of the rated capacity under + 70℃.
*Low-temperature discharge performance is good, standard type batteries: single cell discharge capacity > 40% of rated capacity at
-30℃; low-temperature batteries: single cell discharge capacity > 50% of rated capacity at - 40℃; battery packs discharge
efficiency is more than 70%-75%. With more cells of the battery pack, the discharge efficiency will continue to increase.

Application

lithium ion battery has good safety performance, green environmental protection, does not contain cadmium, lead, mercury and other metal pollutants. Products are widely used in Fire emergency lights, Solar street lighting, National power grid, Telecommunications, Power storage, 5G base station, Electric tools, Electric bicycles, UAVs, Robot, Surveillance cameras, medical devices.

Product Specification

Type	Typical capacity mAh	Min capacity mAh	Max Weight (g)	Internal Resistance (mΩ)	Nominal Voitage (V)	Diameter (mm)	Height (mm)	Max Discharging Rate
IFR 14500	600	500	20	＜50	3.2	14±0.2	50±0.5	2C
IFR 18500	1200	1000	32	＜50	3.2	18±0.2	50±0.5	2C
IFR 18650	1600	1300	42	＜50	3.2	18±0.2	65±0.5	2C
IFR 21700	3000	2800	52	＜50	3.2	21±0.2	70±0.5	2C
IFR 22430	1600	1400	45	＜50	3.2	22±0.2	43±0.5	2C
IFR 22650	2200	2000	62	＜50	3.2	22±0.2	65±0.5	2C
IFR 26650	3600	3000	85	＜50	3.2	26±0.2	65.5±0.5	2C

Why Choose Us

Dison guarantee high quality products.

28 years of R&D and production experience.

Fully automatic production line.

OEM & ODM service.

Prompt on-time delivery.

Service with heart .

Company Profile

Dison group was founded in 1993, with area of 102000 m2, building area of 66000 m2, total asset of 1050 million RMB and 770 employees. DISON has more than 10 fully automated advanced production lines of lithium-ion batteries and Ni-MH batteries, with annual output of more than 150 million cells and 300,000 battery packs. DISON is one of the top 10 battery manufacturers in China and is standing member of CIAPS (China Industrial Association of Power Sources).DISON products are widely used in fire emergency lighting,

solar street lighting, State Grid, communication, energy storage, 5G station, medical, electric tools, electric bicycle, electric vehicle, drone, AI and many other fields. As battery enterprise, DISON participated in the drafting and relevant testing of the national standard lighting and evacuation indication system>, and participated in the drafting and compile of several national standards of lithium-ion batteries used for electric bicycles. More than 90% of the emergency lighting of the national key projects are equipped with DISON batteries. The 12 main venues of the

29th Beijing Olympic Games, such as the bird's nest, water cube, Beijing West Railway Station, South Railway Station and capital airport are equipped with DISON batteries.

Product packaging
